Diagnostic
Nidek SLO Mirante
Ultimate multimodal fundus imaging platform that combines high definition SLO and OCT with ultra wide field imaging.
-
The ultimate multimodal imaging platform(- SLO / FA / ICG / Blue-FAF / Green-FAF / Retro mode
- OCT / OCT-Angiography) -
163 wide field and ultra 4K HD image
-
Unsurpassed color ( red, green, and blue wavelengths)
Nidek OCT RS3000
Retina Analysis, Glaucoma Analysis, AngioScan, SLO,Fundus camera
-
Accurate image capture with a SLO-based eye tracer
-
Scan speed (Up to 85,000 A-scans / s)
-
Angle of view (400 x 300 (zoom: 200 x 150)
Nidek OCT RS-330 DUO
Combined OCT and fundus camera system
-
Easy operation with 3-D auto tracking, auto shot, and user friendly interface
-
High definition images (12-megapixel camera)
-
Wide area scan (12 x 9 mm)
-
Scan speed (Up to 53,000 A-scans / s)
Nidek Microperimeter MP-3
-
Fixation test with a precise tracking system
-
High resolution non-mydriatic fundus camera(12-megapixel camera)
-
Scotopic microperimetry
-
Auto tracking and auto alignment
Nidek Laser Speckle Flowgraphy
-
Non-invasive, real-time imaging and quantitative assessment of retinochoroidal blood flow
-
MBR (Mean Blur Rate) measures relative blood flow velocity which correlates to the actual rate of blood flow
-
Multifunctional analysis(Optic nerve head analysis, Retina blood vessel analysis, Waveform parameter analysis)
Nidek Gonioscope GS-1
-
Instant documentation of the iridocorneal angle in real-color photographs
-
Capturing area -Approximately 2.36 mm (circumference direction) x 2 mm (diameter direction)
-
Automated circumferential goniophotography
-
Non-contact gel immersion measurement
-
Display 9.0-inch (WXGA) color LCD touch screen
Nidek Auto Fundus Camera AFC-330
-
Five automated functions for enhanced ease-of-use (3-D auto tracking,Auto focus,Auto switching from anterior eye to fundus,Auto shot,Auto print / export)
-
Working distance 45.7 mm (from objective lens to cornea)
-
Angle of view 450 (330 in small pupil photography mode)
-
Display Tiltable 8.4-inch color LCD touch screen
Nidek Slit-Lamp SL-2000
-
Microscope Type - Galilean converging binocular, five-level magnification
-
Objective lens focal length- f=125 mm
-
Total magnification / diameter of real field of view- 5x / 40.7 mm, 8x / 25.7 mm, 12.5x / 16.1 mm, 20x / 10.1 mm, 32x / 6.4 mm
-
Light source- LED lamp (white)
Nidek Slit-Lamp SL-1800
-
Microscope Type - Galilean converging binocular, five-level magnification
-
Objective lens focal length- f=125 mm
-
Total magnification / diameter of real field of view- 5x / 46 mm, 8x / 29.5 mm, 12.5x / 18.4 mm, 20x / 11.5 mm, 32x / 7.5 mm
Nidek Slit-Lamp SL-450
-
Slit length 1 to 8 mm continuously variable, 0.2, 1, 2, 3, 5, 8 mm
-
Range of tilting angle 0 to 20˚
-
Microscope Type - Greenough Converging Binocular
-
Total magnification 10x, 16x
-
Light source 6 V, 27 W tungsten lamp
-
Diopter adjustment range ±8 D (10x) ±10 D (16x)
Nidek Slit-Lamp SL-250
-
Slit length 0.2,1,2,3,5,8 mm
-
Microscope Type- Greenough Converging Binocular
-
Total magnification 10x, 16x
-
Light source 6 V, 27 W tungsten lamp
-
Diopter adjustment range ±8 D (10x) ±10 D (16x)
Nidek Specular Microscope CEM-530
-
Capture field (0.25 (W) x 0.55 (H) mm)
-
Capture position Central 1 point,Paracentral 8 points (1.3 mm),Peripheral 6 points (7.3 mm)
-
Capturing images(at 1 measuremt) 16 images
-
Alignment -Auto tracking（3D, 2D, Manual）, Auto shot
-
Pachymetry measurement range (300 to 1000 µm)
Nidek Optical Biometer AL-Scan
-
10 seconds to measure 6 values(Axial length,Corneal curvature radius,Anterior chamber depth,Central corneal thickness,White-to-white distance,Pupil size)
-
3-D auto tracking and auto shot
-
Anterior segment observation with Scheimpflug imaging and double mire ring keratometry
Nidek Echoscan US-4000
-
Three-in-One unit of B-scan, biometer, and pachymeter
-
Probe B-Scan(10 MHz),Biometer(10 MHz solid probe),Pachymetry(10 MHz solid probe)
-
IOP correction available
-
Display 8.4-inch color LCD (XGA: 1024 x 768)
